STNDL

LED Steady/Flashing Lights & Electric Horn Max.105dB

CE_COCCE_DOC
Product Feature:30 Built-in Sounds (Max. 105dB at 1m), 30 MP3 User-Defined Sounds (Max. 98dB at 1m)
Voltage:DC:12V, 24VAC:110V-220V
Dimension:Lens Diameter : Ø80Body Diameter : Ø119Height : 267-547
Materials:Lens-ASHousing-ABSReflector-Heat resistant ABS
Protection rating:IP54
IP5498dB105dB-30℃ ~ +50℃LED Steady-Flashing TypeHornNPN-Transistor TypeRoHSSD Card(MP3)
STNDL-N
STNDL-N

Product Feature

  • Combination of warning light and horn allows transmission of both visual and audible signals together
  • Appropriate sound tones can be chosen depending on the various working environments among the various type of available sound tones
  • Sound tone selector and volume controller in front of the device allows convenient use
  • SDcard type allows user defined sound tone
  • Built-in 30 sound tones, support binary and bit input modes
  • Bit input mode consists of 5 sound types with 6 groups. Choose one of the groups to play 5 sounds from that group.(MP3 is separate from the 6 groups)
  • Materials : Lens-AS, Housing-ABS, Reflector-Heat resistant ABS
  • Lens colors are interchangeable
  • Ambient operating temperature -30°C to +50°C
  • Protection rating : IP54
  • Certificates : CE Compliant
  • Compliant with RoHS directive

Product Specifications

Model number layer Voltage Sound Pattern and Volume Certificates Weight Color
STNDL
Steady

STNDLF
Steady/Flashing
1 DC12V

· WS-Warning sound

· WP-Special warning sound 1st group

· WM-Melody

· WA-Alarm

· WO-Special warning sound 2nd group

· WN-Special warning sound 3rd group



· Bit Input: 5Ch

· Binary Input: 30Ch

· Built-in sounds: Max.105dB (Based on WS-Ch5)

· MP3: Max.98dB

CE DC-1.19kg
AC-1.58kg
R-Red
DC24V

AC110V

-220V

2 DC12V DC-1.43kg
AC-1.82kg
R-Red
G-Green
DC24V

AC110V

-220V

3 DC12V DC-1.67kg
AC-2.06kg
R-Red
A-Amber
G-Green
DC24V

AC110V

-220V

4 DC12V DC-1.91kg
AC-2.30kg
R-Red
A-Amber
G-Green
B-Blue
DC24V

AC110V

-220V

5 DC12V DC-2.15kg
AC-2.54kg
R-Red
A-Amber
G-Green
B-Blue
W-White
DC24V

AC110V

-220V

ㆍLens colors are interchangeable

ㆍAmbient operating temperature: -30°C to +50°C

※ CE compliant: DC24V, AC110V, AC220V

※ When playing MP3 files, there may be difference of volume depending on user’s audio file type.





Light source/signal sound current(based on 1 layer)

Voltage
DC12V
DC24V
AC110V-220V
Light source current(1 layer)
160mA
95mA
Max.70mA
Signal sound current 285mA 185mA Max.105mA

Sound Tone Combination of Standard Product

5 Warning Sounds

Fire.A-ANG

Channel.1

Emergency WA-U(Yelp)

Channel.2

Ambulance PI-PO(Hi-low)

Channel.3

Machinery Fault

Channel.4

High Expansion

Channel.5

5 Melodies

Sweet Home

Channel.1

For Elise

Channel.2

Cuckoo's Waltz

Channel.3

Piano Sonata

Channel.4

Turkish March

Channel.5

5 Alarms

Beep Intermittent

Channel.1

Door Chime

Channel.2

Phone Ring

Channel.3

PI.PI.PI. Short Interval

Channel.4

Tripping Beat

Channel.5

5 Special Warning Sounds (1st Group)

Fire.A-ANG

Channel.1

Abandon Alarm

Channel.2

Machinery Fault

Channel.3

High Expansion

Channel.4

7 Short PI. / 1 Long

Channel.5

5 Special Warning Sounds (2nd Group)

Rel rel rel

Channel.1

Slow Ambulance PI-PO

Channel.2

Emergency WA-U(Yelp)

Channel.3

Phone Ring

Channel.4

Fire.A-ANG

Channel.5

5 Special Warning Sounds (3nd Group)

Oit Oit warning sound

Channel.1

Pi o Pi o

Channel.2

Slow Di o Di o

Channel.3

Li long Li ling

Channel.4

911 Siren

Channel.5
